€12.49
Artiteq back Frame Photo Panel Hanging System - self-adhesive

Artiteq Back Frame DiBond Photo Panel Hanging System - self-adhesive

0517300

Easily put together your desired set below. These extra sturdy version aluminum rails are 25mm wide and 15mm high .

You automatically choose 2 x the length and 2 x the width. The corner connectors and hangers are optional = 1 complete frame.

Choose the required length

Rail Width

Volume discounts

QuantityUnit discountYou Save
55%Up to €3.12
1010%Up to €12.49
2515%Up to €46.84
5020%Up to €124.90
10025%Up to €312.25
Number of products
total price

Artiteq Back Frame Hanging System
Safe and solid solution for hanging printed wall panels.

The Artiteq Back Frame Hanging System is a mounting system made of non-anodized aluminum that has been specially developed for thin and flexible wall panels made of aluminum (DiBond), forex or acrylic. It makes the wall panels sturdier and offers easy and safe installation. The Power Corners offer the option of easily leveling already mounted panels (correction up to 6 mm). A safe and solid solution for hanging printed wall panels such as aluminum (DiBond), Forex or acrylic and plexiglass. It creates depth and shadow between the panel and the wall and offers 3 options for hanging printed panels.

The specially designed Power Corners for the Artiteq Back Frame Hanging System offer 3 options for hanging printed wall panels: fixed, secured or flexible. No additional accessories are required as the printed wall panel is hung using the Power Corners and comes with integrated wall protection as standard.

Easy hanging – fixed
The Power Corners offer the option of easily hanging the wall panel level (up to 6 mm correction possible). The Power Corners are supplied with a handy drilling aid that indicates the exact position of the drill holes. There is also an adjustment option after attaching the system behind the printed panel.
Easy hanging – level and secured if necessary
The panel can be mounted to the wall and locked (if necessary) using 2 or 4 Back Frame Clips. The frame hangs from the top two clips and can therefore be hung level very easily. Turning the bottom two Clips with the Security Key locks the frame.
Easy hanging – flexible
The combination of the Artiteq Back Frame Hanging System with a picture hanging system offers flexibility and ease of use when decorating your walls. The suspension wire is placed through the Power Corner and the suspension hooks in the lower Power Corners to prevent tipping as much as possible.

Where possible, try to leave approximately 5-10cm from each side for maximum load-bearing capacity. If desired, you can cut the rail to size yourself with a hacksaw.

The load-bearing capacity depends on many factors, such as the surface and the material of the (photo) panel itself. It is also very important to thoroughly clean the surface to be stuck with an alcohol cleaner and to wait at least 72 hours before hanging the object.

We recommend using our Back Frame System for printed panels made of aluminum (DiBond), hard foam, Forex, acrylic and glass. Our tape can support a panel of up to 4 square meters with a maximum total weight of 25kg and minimum dimensions of 400 x 400 mm when the profiles of the Back Frame Hanging System are placed at a maximum distance of 100 mm from each side of the printed panel.

0517300

Data sheet

Colour
Aluminium
Delivery time
In stock
Rail width
25mm
Rail height
16mm

Specific References

Download

Artiteq Back Frame

Download (254.3KB)

Artiteq Back Frame Secure

Download (104.01KB)
